Shurtape EV077B Black Electrical Insulation Tape – 3/4-Inch × 66-Foot, 10-Pack

Description

EV 077B Professional Grade Black Electrical Tape for Insulating & Splicing – 3/4″ x 66′ – 10-Pack

Professional grade, 7.0 mil, all-weather vinyl insulating tape used for electrical and mechanical protection in temperatures ranging from 0 F to 220 F. UL Listed and CSA Approved, EV 77B black electrical tape is lead-free, flame retardant, and is engineered with a polymeric backing construction, as well as a specialized method of bonding the adhesive to the vinyl backing, which allows the tape to be highly conformable and deliver a moisture-tight seal, even in extreme temperatures.

Features:

• 7.0 mil, professional-grade electrical tape
• High tensile strength
• High performance in a wide temperature range
• Resistant to UV, oils, acids, alkalies, corrosive chemicals, and water
• Flame retardant

Technical Specifications:

• Tape Width – 3/4″
• Roll Length – 66′
• Adhesive – Non-corrosive, rubber-based
• Adhesion to Stainless Steel – 28 oz/in width
• Dielectric Breakdown – 10,000V
• Dielectric Strength – 1,429V/mil
• Elongation – 300%
• Service Temperature Range – 0°F-220°F
• Tensile – 20 lbs/in width
• Thickness – 7.0 mils
• Color – Black
